Available Sizes:
½” to 4” / DIN 15 - DIN 150
Standards
3A/SMS/DIN/RJT/I DF
Material
304/316L stainless steel
Gasket
silicon seats /EPDM
Type
2 ways / 3 ways
Surface Finish
Ra ≤ 0.8μm
Connections
Triclover End
Operation type
Manual
Maximum Pressure
1.0" - 4.0" to 5 bar at 68°F (20°C)
Temperature / Vacuum
to 1 bar at 68°F (20°C),
temperature rating
15°F to 200°F (10°C to 95°C)
Application
dairy/food/pharma/beverage/chemical/cosmetic
Marking
laser marking
